LED Wash Bar (Pixel Bar)

bar

DYNAMIC WALL WASHING AND CREATIVE PIXEL EFFECTS!

Transform any venue with the LED Wash Bar, a versatile fixture designed for wide-area saturation and intricate visual patterns. Whether you are uplighting a corporate gala’s perimeter or creating dynamic “running” effects behind a DJ booth, this linear bar delivers smooth color mixing and high-intensity output. With multiple independently controllable segments, it allows lighting designers to go beyond simple color fills and create mesmerizing pixel-mapped animations that bring the stage to life.

Categories: ,

Description

Discover the professional LED Wash Bar. Engineered for both architectural accenting and live stage effects, this fixture features a high-output LED array with a wide beam angle for even coverage. Its slim, low-profile design allows it to be tucked into tight corners for wall washing or mounted on truss for aerial effects. Featuring flicker-free operation and seamless DMX integration, it is the perfect choice for high-definition broadcasts and professional event productions.

  • Voltage: AC100V-240V 50/60Hz

  • Light Source: 24 x 10W RGBW 4-in-1 LEDs (Typical)

  • Power Consumption: 250 W

  • Control Segments: 8 independently controllable sections (Pixel mapping)

  • Beam Angle: 40° (Wide-angle wash)

  • Color Mixing: RGBW Linear mixing with vibrant saturation

  • Strobe: 0-20Hz electronic strobe

  • Dimmer: 0-100% linear electronic dimming

  • Control Mode: DMX512 (Standard 9/38 Channels), Auto, Master-Slave

  • Display: 4-digit LED control panel

  • Cooling: Silent convection cooling (No fans)

  • Protection Rating: IP20 (Indoor) / IP65 (Outdoor options available)

  • N.W: 4.5 KG

  • Dimensions: 1000 * 130 * 150 mm
